Ariston Egis 24 FF NG Display PCB Ref. 65105084
Ariston display module, catalogue reference 65105084. The photographed label identifies the part as DISPLAY AR GAL BASIC; it is not the main control board for the burner and pump. Before buying, compare the complete label, connectors and the parts diagram for your model. A display fault requires professional diagnosis: the power supply or wiring may also be the cause.
Ariston boilers compatible with reference 65105084
PCB with reference 65105084. 11 verified compatibilities: EGIS 24 FF NG and EGIS 24 FF GPL.
Proven compatibility
| Boiler model | Family | Verification |
|---|---|---|
| Ariston EGIS 24 FF NG | Egis 24 | Contrasted |
| Ariston EGIS 24 FF LPG | Egis 24 | Contrasted |
| Ariston EGIS 24 CF NG | Egis 24 | Contrasted |
| Ariston EGIS 24 CF LPG | Egis 24 | Contrasted |
| Ariston AS 24 FF NG | AS 24 | Contrasted |
| Ariston AS 24 FF LPG | AS 24 | Contrasted |
| Ariston AS 24 CF NG | AS 24 | Contrasted |
| Ariston AS 24 CF LPG | AS 24 | Contrasted |
| Ariston BS 24 CF | BS 24 | Contrasted |
| Ariston BS 24 FF | BS 24 | Contrasted |
| Ariston BS 24 FF LPG | BS 24 | Contrasted |
Can't see your model or have questions? The printed reference takes precedence. How to check it · Send us a photo via WhatsApp.
How to check if the ref. 65105084 is the part for your boiler
The part reference, model, and equipment revision must be verified against the manufacturer's documentation.
- Find the reference printed on the installed part and check whether it matches the catalogue reference 65105084. If it is not visible, do not identify the part from its shape alone.
- Check the full boiler model on its data plate and look for it in the model associations on this page.
- Compare the connections and physical body with the original part before installation.
- If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.
Symptoms that require diagnosis on the PCB 65105084
The PCB controls the ignition, modulation, and safety features of the boiler. These are the typical symptoms and what to do:
Common symptoms and faults
- 01
The boiler display does not turn on or remains blank.
Cause: The display board is not receiving power from the main board or the cable connecting them is poorly connected.
Check that the connector or flat cable between the display board and the main PCB is properly seated and undamaged before replacing the screen.
- 02
The display does not show the temperature or the fault codes.
Cause: Communication has been lost between the display PCB and the main PCB, although the latter continues to function.
Check if the boiler heats normally despite the screen being off: if it heats, the fault is with the screen, not with the boiler control.
- 03
The buttons or the display are not responding.
Cause: The buttons integrated into the display board have lost continuity or the module itself has failed.
Turn off the power to the boiler from the main switch, wait a minute, and turn it back on to see if the buttons respond before considering the display faulty.
Ariston fault codes that require diagnosis
| Code | Fault | Technical checks |
|---|---|---|
| 70 | EEPROM error / logical operation anomaly of the boiler. | Fault in the EEPROM memory or in the logic of the main PCB (this same part, ref. 65105084): the board does not read/write its parameters correctly. Check by turning the boiler off and on; if after the RESET the 70 persists, the cause is the board and it should be replaced. |
These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.
Data sheet for the Ariston PCB 65105084
- Catalogue reference
- 65105084
- Uniclima internal SKU
- ECN-92d060270X
- Brand
- Ariston
- Type of part
- PCBs (control boards)
- Units in stock
- 2 units
- Status
- Refurbished
- Warranty
- 1 year
- Shipping
- Delivery time shown at checkout
- Return
- 14 days
Part data and available documentation
Contrast the label codes, PCB, and revision with the installed part; they are not necessarily equivalent references.
- Product identification
- Display PCB Ariston Egis/AS/BS 24 CF/FF, commercial reference 65105084
- Product code on label
- 000342008800 - DISPLAY AR GAL BASIC
- Firmware version
- SW MICRO 01.00.07_LED
- Control unit code
- 30410821 - CENT.MTS Ariston LED
- Country of manufacture
- MADE IN P.R.C.
- Batch/date marking of this unit
- 3310 20 J8 2289
Frequently asked questions about the PCB 65105084
Is the PCB Ref. 65105084 the main board of the Ariston Egis 24 FF or just the display?
Is the screen PCB Ref. 65105084 compatible with an Ariston EGIS 24 CF NG?
Does the BOARD code 480140000800 on the label correspond to the commercial reference 65105084?
How many models are compatible with the PCB Ref. 65105084?
What fault codes are documented for this PCB?
