Saunier Duval Opalia C 11 G Electronic Ignition Module Ref. S1221400

Saunier Duval boilers compatible with reference S1221400

PCB with reference S1221400. 14 verified compatibilities: OPALIAC11 and OPALIAC11P.

Proven compatibility

Can't see your model or have questions? The printed reference takes precedence. How to check it · Send us a photo via WhatsApp.

How to check if the part S1221400 is the one for your boiler

The part reference, model, and equipment revision must be verified against the manufacturer's documentation.

1. Find the reference printed on the installed part and check whether it matches the catalogue reference S1221400. If it is not visible, do not identify the part from its shape alone.
2. Check the full boiler model on its data plate and look for it in the model associations on this page.
3. Compare the connections and physical body with the original part before installation.
4. If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.

Symptoms that require diagnosis on the PCB S1221400

The PCB controls the ignition, modulation, and safety features of the boiler. These are the typical symptoms and what to do:

Common symptoms and faults

• 01

  The boiler tries to ignite the burner but fails to light.

  Cause: The module does not generate the high voltage spark when the gas is opened.

  Check that the ignition electrode is clean and properly positioned at the correct distance before replacing the module.

• 02

  There is no spark visible at the burner, although there is a smell of gas.

  Cause: The module produces the electric arc; without a spark, the gas comes out but does not ignite.

  Cut off the gas immediately if there is a smell without ignition, and check the high voltage cable of the electrode for any damage or looseness.

• 03

  The boiler ignites for a moment and then turns off immediately, as if it shuts down by itself.

  Cause: The module can generate the spark but fails to maintain the ignition, so the flame does not stabilize.

  Pay attention to the color of the flame at that moment if it is visible: an irregular flame indicates a problem with the gas rather than the module.

• 04

  The display shows a lock or warning related to the ignition.

  Cause: The control board detects that there was no proper ignition within the safety time and translates it into that warning.

  Reset the boiler once and observe if the fault occurs again at the same point in the ignition sequence.

These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.

Data sheet for the Saunier Duval S1221400 PCB.

Catalogue reference

S1221400

Uniclima internal SKU

CEOC11G

Brand

Saunier Duval

Type of part

PCBs (control boards)

Units in stock

1 unit

Status

Refurbished

Warranty

1 year

Shipping

Delivery time shown at checkout

Return

14 days

Part data and available documentation

Contrast the label codes, PCB, and revision with the installed part; they are not necessarily equivalent references.

Model

SD-102-2

Code

10005349

Serial number

P007422

Input voltage

DC 1.5V

Output voltage

MIN 12KV

Batch code / quality control

05 12 / FQC
