Water Fitting Junkers Euromaxx ZWC 24 1 MF2A 23
RefurbishedJunkersHydraulic units

Water Fitting Junkers Euromaxx ZWC 24 1 MF2A 23

Stock · 7 units

The water fitting Junkers Euromaxx ZWC 24 1 MF2A 23 is a hydraulic component that conducts and distributes water between the circuits of the boiler. When this part fails, you may notice leaks, loss of pressure, or issues with the production of domestic hot water. This fitting is compatible with several models, including the ZWC 24-1 MF2A 23, ZWC 24-1 MF2A 31, and others from the ZC range. It is recommended to replace the part when these symptoms occur to avoid further damage.

VAT included

Compatibility

Compatible Junkers boilers

Hydraulic group. Eight confirmed compatibilities: 24-1 MFA 23 and 24-1 MFA 31.

Proven compatibility

Boiler modelFamilyVerification
Junkers 24-1 MFA 23ZCContrasted
Junkers 24-1 MFA 31ZCContrasted
Junkers 28-1 MFA 23ZCContrasted
Junkers 28-1 MFA 31ZCContrasted
Junkers 24-1 MF2A 23ZWCContrasted
Junkers 24-1 MF2A 31ZWCContrasted
Junkers 28-1 MF2A 23ZWCContrasted
Junkers 28-1 MF2A 31ZWCContrasted

Can't see your model or have questions? The printed reference takes precedence. How to check it ·

Guide

How to check if it is the part for your boiler

What determines it is not the boiler model, but the reference printed on the part you already have installed.

  1. Find the reference printed on the installed part and check whether it matches the catalogue reference —. If it is not visible, do not identify the part by its shape alone.
  2. Check the full boiler model on its data plate and look for it in the model associations on this page.
  3. Compare the connections and physical body with the original part before installation.
  4. If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.
Diagnosis and fault codes

Symptoms and faults that the hydraulic group resolves

The hydraulic group includes the valve, the by-pass, and the water connections. These are the typical symptoms and what to do:

Common symptoms and faults

  • 01

    There is a water leak at the T connection, where the three sections of pipe meet.

    Cause: It is the point that bears the most mechanical stress, and the plastic yields there before in the rest of the pipe.

    Check the three arms of the T-piece separately: if moisture is coming from only one, it might be the pipe and not the T-piece itself.

  • 02

    The white clip that holds the connection is broken or does not fit properly.

    Cause: That clip keeps the tube inserted under pressure; if it breaks, the connection loses tightness even though the body of the T is intact.

    Before replacing the entire part, check if only the clip is damaged and if any securing teeth are missing.

  • 03

    A small whistling or gurgling sound can be heard near that area when the boiler is running.

    Cause: If the connection is not completely sealed, air can enter the circuit and generate that noise.

    With the boiler on, bring your ear close to the T area without touching it to determine if the noise is coming from there.

  • 04

    The part moves or is loose when touched, even though it hasn't started leaking yet.

    Cause: With the worn clip, the fitting loses the press-fit and becomes loose before it starts to leak.

    Check by hand, without forcing, if the T-joint has play relative to the pipes it connects: if it moves, it's only a matter of time.

These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.

Technical data

Junkers hydraulic group datasheet

Brand
Junkers
Type of part
Hydraulic units
Units in stock
7 units
Status
Refurbished
Warranty
1 year
Shipping
Delivery time shown at checkout
Return
14 days
Documentation

Manuals and technical documentation

Official documentation of the boiler, useful for locating the part and cross-referencing the fault codes.

Frequently Asked Questions

Frequently asked questions about the hydraulic group

Is this T-fitting suitable for the Junkers Euromaxx ZC 24-1 MFA 23?
Yes, it is compatible with versions 23 and 31 of the ZC 24-1 MFA, ZC 28-1 MFA, ZWC 24-1 MF2A, and ZWC 28-1 MF2A.
What does the T-fitting of the ZWC 24-1 MF2A physically look like?
It is made of black plastic, with a ribbed grip area and a white clip connector.
Is this T-fitting suitable for both the ZC 24-1 and the ZWC 24-1 MF2A?
Yes, the part is compatible with both series, ZC 24-1/28-1 MFA and ZWC 24-1/28-1 MF2A, in versions 23 and 31.
