Vaillant Electronic Display Module VMW 232 1 Turbocombi Ref. 130836
The Vaillant VMW 232 1 Turbocombi Electronic Display Module Ref. 130836 is a control PCB that manages the ignition, burner modulation, pump, and safety features of the boiler. When it fails, the boiler may not start, become locked, or exhibit erratic behavior. The user may notice the fault F.70, which indicates a specific invalid appliance number on the display and/or on the main board, suggesting a communication failure. This module is compatible with the Vaillant Turbocombi VMW 232-1 boiler, among others. It is recommended to replace it when the mentioned symptoms occur to avoid further issues.
VAT included
Consult via WhatsAppVaillant boilers compatible with reference 130836
PCB with reference 130836. A proven compatibility: VMW 232-1.
Proven compatibility
| Boiler model | Family | Verification |
|---|---|---|
| Vaillant VMW 232-1 | Vaillant Turbocombi VMW | Contrasted |
Can't see your model or have questions? The printed reference takes precedence. How to check it · Send us a photo via WhatsApp.
How to check if the part number 130836 is the one for your boiler
What determines it is not the boiler model, but the reference printed on the part you already have installed.
- Find the reference printed on the installed part and check whether it matches the catalogue reference 130836. If it is not visible, do not identify the part from its shape alone.
- Check the full boiler model on its data plate and look for it in the model associations on this page.
- Compare the connections and physical body with the original part before installation.
- If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.
Symptoms and faults that the PCB 130836 resolves.
The PCB controls the ignition, modulation, and safety features of the boiler. These are the typical symptoms and what to do:
Common symptoms and faults
- 01
The control panel display does not turn on at all, neither with dim light nor blinking.
Cause: The display module is damaged and does not turn on, although the rest of the boiler operates correctly.
Check that the boiler has power and that the main fuse has not blown, to rule out a general power supply issue.
- 02
The display shows no data or icons, although it is noticeable that the boiler is on due to the noise of the burner.
Cause: The display module may fail while the rest of the boiler continues to operate.
Check if the heating or the domestic hot water are still functioning normally; if so, the fault is limited to the panel.
- 03
The control panel does not respond to any button presses, although it seems to have power.
Cause: The panel keyboard is a separate component from the screen and may become unresponsive.
Test each button separately and repeat the pressing several times before concluding that the entire module is faulty.
Fault codes from Vaillant that this part resolves.
| Code | Fault | Diagnosis and solution |
|---|---|---|
| F.70 | Invalid specific device number (DSN) on display and/or main PCB. | The display module 130836 can cause F.70 if it is replaced (alone or together with the PCB) without programming the DSN or if the coding does not match the main PCB; verify by entering the diagnostic menu and checking/adjusting the DSN and ensuring that the display/PCB correspond to the model. |
| with | Communication fault: no communication between display and main PCB. | The display module 130836 (or its wiring/connector) may fail and lose communication with the main PCB; check the continuity of the harness/flat and display connections, and if the issue persists, test with a known good display. |
These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.
Vaillant electronic PCB data sheet 130836
- Catalogue reference
- 130836
- Brand
- Vaillant
- Type of part
- PCBs (control boards)
- Units in stock
- 6 units
- Status
- Refurbished
- Warranty
- 1 year
- Shipping
- Delivery time shown at checkout
- Return
- 14 days
Frequently asked questions about the PCB 130836
Is this module suitable for a Vaillant VMW 230-1?
When should this display module be replaced in the VMW 230-1?
