Roca NYE43-15 P Ku circulator pump · 4512937 for Baxi Roca Vega 20
Bomba circuladora que hace circular el agua por el circuito de la caldera. Aplicación pendiente de confirmar. Los radiadores fríos con la caldera encendida, el ruido, la vibración y el eje agarrotado tras una parada larga son síntomas asociados a la bomba Baxi Roca DYA43-15 P, un modelo distinto; no permiten diagnosticar esta unidad por sí solos.
- Type of part
- Baxi Roca
- Status
- Refurbished
- internal SKU
- BOM053
- Warranty
- 1 year
VAT included OUT OF STOCK
Compatible Baxi Roca boilers
A proven compatibility: Baxi Roca Vega 20.
Proven compatibility
| Boiler model | Family | Verification |
|---|---|---|
| Roca Vega 20 | Baxi Roca | Contrasted |
Can't see your model or have questions? The printed reference takes precedence. How to check it · Send us a photo via WhatsApp.
How to check if it is the part for your boiler
The part reference, model, and equipment revision must be verified against the manufacturer's documentation.
- Look at the motor plate: it should say NYE43-15 P Ku and the code 4512946.
- Also compare reference 4512937 and the data from the PCB: 230 V, 88 W, and capacitor of 2.6 µF.
- Do not confuse it with the NYL 43-15 (195000050) or the DYA43-15 P (122075100): they are different models with different codes.
- Measure your pump: a similar model (Salmson NYE 43-15-Ku P) has 1" and 130 mm, without confirming that it is the same part.
- If they match, call us at 911 17 77 77 with your boiler model and we will confirm availability.
Technical sheet: Baxi Roca
- Uniclima internal SKU
- BOM053
- Brand
- Baxi Roca
- Type of part
- Baxi Roca
- Units in stock
- 0 units
- Status
- Refurbished
- Warranty
- 1 year
- Shipping
- Delivery time shown at checkout
- Return
- 14 days
Part data and available documentation
Contrast the label codes, PCB, and revision with the installed part; they are not necessarily equivalent references.
- Commercial reference
- 4512937
- Code marked on the PCB
- 4512946
- Additional marking on the PCB
- 23/05 - 005656
- Voltage
- 1~230 V
- Frequency
- 50 Hz
- Condenser
- 2.6 μF; 400 V
- Thermal insulation / protection class
- Class F; TF95
- Nominal pressure / degree of protection
- PN6; IP44
- Power (speed 1)
- 88 W
- Current
- 0.38 A
- Origin
- Manufactured in the EU
- Conformity marking
- CE
- Source of additional data
- Declared information; auxiliary references and applications without equivalent from the accredited manufacturer.
- Inventory — Thermal insulation/protection class
- Class F; TF95
- Inventory — Marked consumption
- 88 W; 0.38 A
- Inventory — Protection
- PN6; IP44; Class F; TF95
- Inventory — Origin printed on label
- Made in EU
- Speeds data
- One
- Class · thermal protection
- Class F · TF95
- list NYE 43-15-Ku P (not confirmed that it is the same part) — Brand on that
- Salmson (the brand like Baxi Roca) · spare parts
- list NYE 43-15-Ku P (not confirmed to be the same part) — Power · rotation speed
- 88 W · 1850 rpm · spare parts
- what is the measurement for NYE 43-15-Ku P (not confirmed that it is the same part)
- 1" · 130 mm · spare parts
- list NYE 43-15-Ku P (not confirmed to be the same part) — Flue
- Plastic spare parts
Before purchasing
- Do not confuse: 195000050 — Baxi Roca circulator NYL 43-15 (also 321018816), which is for Roca Alba, Gavina, and Laia — It is another model (NYL): it indicates TF110 and 1.0 MPa; this pump marks TF95 and PN6.
- Do not confuse: 122075100 — Baxi Roca recirculation pump DYA43-15 P, for Roca RS-20 and RSI-20/20 — It is another model (DYA), with a different code.
- Do not confuse: 122627451 — Baxi Roca circulator that independents provide for the Vega 20 AIM/AIFM — Different code. confirmed the NYE43-15 P Ku in the Vega 20; if your pump shows another code, compare it.
- The model also appears as NYE43-15P Ku. NYE 43-15-Ku P (brand Salmson) without mentioning Baxi Roca or the codes: it is not confirmed that it is the same part.
- Registered confirmation: model, codes, and the Vega 20. Outside, just combine 4512937, 4512946, and NYE43-15 P Ku; another list NYE 43-15-Ku P (Salmson) without mentioning Baxi Roca or codes (its goal mentions Ferroli). No official manual or catalog read provides the pump code.
Frequently asked questions: Baxi Roca
Where is the code for the Baxi Roca NYE43-15 P Ku pump and what else should I compare?
On the motor PCB: the model NYE43-15 P Ku and the code 4512946. The commercial reference is 4512937. The technical sheet provides the same data: Typ NYE43-15 P Ku, Class F - TF95, P/N 4512937 and "other identifiers" 4512946. Also compare 230 V, 88 W and the capacitor of 2.6 µF.
Is it compatible with my Baxi Roca Vega 20 boiler?
Yes. Confirmation registered: this pump (NYE43-15 P Ku, 4512937) for the Baxi Roca Vega 20. Without additional external confirmation, it is linked to the Vega 20, and different ones are provided for the Vega 20 AIM/AIFM another circulator, the 122627451. If your pump shows another code, compare it; any doubts? Send us a photo of your pump's label from Contact or call 911 17 77 77.
Is the NYE43-15 P Ku the same as the NYL 43-15 or the DYA43-15 P?
No, they are different models with other codes. The NYL 43-15 (Baxi Roca 195000050) is provided for Roca Alba, Gavina, and Laia, with TF110 and 1.0 MPa; this pump marks TF95 and PN6. The DYA43-15 P (122075100) is provided for Roca RS-20 and RSI-20/20. Pay attention to the letters (NYE, NYL, DYA) and the code.
What do 4512937, 4512946, and NYE43-15 P Ku mean?
The model of the pump is NYE43-15 P Ku (Type NYE43-15 P Ku). 4512937 is the commercial reference (P/N) and 4512946 is the code marked on the motor plate, which serves as "another identifier." A similarly designated model (Salmson NYE 43-15-Ku P, 88 W, 1850 rpm) is mentioned without citing Baxi Roca or these codes. Without additional confirmation, each figure indicates the following:
- NYE43: This typically refers to the series or type of the pump.
- 15: This usually indicates the flow rate or capacity of the pump, often measured in liters per minute.
- P: This may denote a specific feature or variant of the pump.
- Ku: This could refer to the design or application type.
- 88 W: This indicates the power consumption of the pump, measured in watts.
- 1850 rpm: This specifies the rotational speed of the pump's motor, measured in revolutions per minute.
What technical data does the NYE43-15 P Ku have?
To confirm: According to the label of our unit: 1~230 V · 50 Hz, 88 W (speed 1) and 0.38 A, capacitor of 2.6 µF · 400 V, class F with TF95, PN6 and IP44. Confirm class F, TF95 and a single speed. The model listed as Salmson also states 88 W and adds 1850 rpm, 1" and 130 mm and plastic volute, but does not mention Roca or the codes: measure your pump.
Does it also fit in other boilers besides the Vega 20?
Unconfirmed: other specific boilers. A model with a similar designation (Salmson NYE 43-15-Ku P) in the categories of diesel boilers Lamborghini and Baxi Roca, without mentioning which models and without confirming that it is the same part. If your boiler is different, please send us a photo of your pump label and the boiler's PCB from the Contact section.
Who should install it?
A qualified technician: the pump operates at 230 V and is part of the water circuit of the boiler. Before ordering it, compare the model NYE43-15 P Ku and the code 4512946 of your pump with those of this one.
What is the reference for this pump?
4512937 · NYE43-15 P Ku
What power supply does it need?
230 V at 50 Hz.
