PCB Vaillant Group Saunier Duval Themafast C 24 E Ref. S1047000

Saunier Duval boilers compatible with reference S10470

PCB with reference S10470. 33 verified compatibilities: F 25 E and F 24 E.

Proven compatibility

Can't see your model or have questions? The printed reference takes precedence. How to check it · Send us a photo via WhatsApp.

How to check if ref. S10470 is the part for your boiler

The part reference, model, and equipment revision must be verified against the manufacturer's documentation.

1. Find the reference printed on the installed part and check whether it matches the catalogue reference S10470. If it is not visible, do not identify the part from its shape alone.
2. Check the full boiler model on its data plate and look for it in the model associations on this page.
3. Compare the connections and physical body with the original part before installation.
4. If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.

Symptoms that require diagnosis on the PCB S10470

The PCB controls the ignition, modulation, and safety features of the boiler. These are the typical symptoms and what to do:

Common symptoms and faults

• 01

  The boiler is completely off, with no indicator lights on, and it does not respond to anything.

  Cause: This PCB is the control center of the entire boiler: if it loses power or malfunctions, the unit will not start at all.

  Check the fuse on the control board itself, if accessible, and the input voltage before replacing it.

• 02

  It smells burnt or there is a dark mark next to some component of the PCB.

  Cause: A voltage spike or a short circuit can damage traces or components of the control electronics.

  With the boiler unplugged, visually inspect the PCB for burns before assuming a replacement is necessary.

• 03

  The boiler works for several days without any issues and then suddenly gets locked, with no clear pattern.

  Cause: An intermittent fault in the control board, such as a solder joint or a capacitor, causes sporadic faults that are difficult to reproduce on demand.

  Keep a record of when the blockage occurs, the time, and whether it coincides with domestic hot water or heating, to see if there is a pattern.

• 04

  The remote control or the control panel stops communicating with the boiler.

  Cause: The PCB is the one that manages communication with the control; if that module fails, the control is left without data.

  Check that the remote control has the correct power supply and that the communication cable or bus is properly connected before replacing the PCB.

Fault codes Saunier Duval that require diagnosis

These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.

Data sheet for the Saunier Duval S10470 PCB.

Catalogue reference

S10470

Uniclima internal SKU

PLSA175

Brand

Saunier Duval

Type of part

PCBs (control boards)

Units in stock

1 unit

Status

Refurbished

Warranty

1 year

Shipping

Delivery time shown at checkout

Return

14 days

Part data and available documentation

Contrast the label codes, PCB, and revision with the installed part; they are not necessarily equivalent references.

PCB reference

S1047000

Supply voltage

230V

Barcode

3532041183024
