PCB Fagor Contract Mini CE 24E N Ref. N03G009M8
Refurbished Fagor PCBs (control boards)

PCB Fagor Contract Mini CE 24E N Ref. N03G009M8

The control PCB regulates the ignition, the modulation of the burner, the pump, and the safety features of the Fagor Contract Mini CE 24E N boiler. If it fails, you will notice that the boiler does not start, locks out, or exhibits erratic behavior, potentially displaying fault codes F5 or F10. This part is compatible with several models, including FE-24E/1 N, CA24E N, and FA23E B, among others. A technician must confirm through diagnosis whether it needs to be replaced when you experience these symptoms or when the boiler has operational issues related to the electronic control.

Type of part
PCBs (control boards)
Status
Refurbished
Catalogue reference
N03G009M8
Warranty
1 year
VAT included Stock · 5 units
Compatibility

Fagor boilers compatible with reference N03G009M8

PCB with reference N03G009M8. 12 verified compatibilities: FE-24E/1 N and FE-24E/1 B.

Verified compatibility

Boiler modelFamilyVerification
Fagor FE-24E/1 NFE24EVerified
Fagor FE-24E/1 BFE24EVerified
Fagor FE-24E H/1 NFE24EVerified
Fagor FE24EC/1 BFE24EVerified
Fagor FE24EC/1 NFE24EVerified
Fagor CA24E BCA24EVerified
Fagor CA24E NCA24EVerified
Fagor FA23E BFA23EVerified
Fagor FA23E NFA23EVerified
Fagor FE27E/1 BFE27EVerified
Fagor FE27E/1 NFE27EVerified
Fagor FE27ECN/1 NFE27EVerified

Can't see your model or have questions? The printed reference takes precedence. How to check it ·

Guide

How to check if ref. N03G009M8 is the part for your boiler

The part reference, model, and equipment revision must be verified against the manufacturer's documentation.

  1. Find the reference printed on the installed part and check whether it matches the catalogue reference N03G009M8. If it is not visible, do not identify the part from its shape alone.
  2. Check the full boiler model on its data plate and look for it in the model associations on this page.
  3. Compare the connections and physical body with the original part before installation.
  4. If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.
Diagnosis and fault codes

Symptoms that require diagnosis on the PCB N03G009M8

The PCB controls the ignition, modulation, and safety features of the boiler. These are the typical symptoms and what to do:

Common symptoms and faults

  • 01

    The boiler ignites and operates normally, but there is a specific function or accessory that is not responding.

    Cause: The auxiliary PCB controls specific functions, and its fault does not always affect the overall operation of the boiler.

    Confirm which function this auxiliary PCB controls in your specific model before replacing it; in the Fagor range, there are several versions.

  • 02

    A fault code appears on the main PCB display even though the problem is in a secondary component.

    Cause: The main PCB detects that the auxiliary one is not responding and indicates it as a communication problem or a specific circuit issue.

    Note the exact code displayed before purchasing, so you can confirm that the fault points to this PCB and not to another element.

  • 03

    The boiler works intermittently: the affected function sometimes works and sometimes doesn't.

    Cause: An emerging fault in the electronics of the auxiliary PCB (solder joints, degraded components) causes intermittent failures before completely stopping functioning.

    Disconnect and reconnect the connectors of the auxiliary PCB; a poor connection can cause the same symptoms and it doesn't cost anything to check it.

  • 04

    The accessory that controls this PCB (a relay, a pump, a specific output) does not start even though the rest of the boiler is working fine.

    Cause: The output from the auxiliary PCB that powers that component has failed, and there is no current reaching the actuator.

    Measure with a multimeter if voltage is reaching the affected component before blaming the PCB.

Fagor fault codes that require diagnosis

CodeFaultTechnical checks
F5Control board fault: internal fault in the electronic circuit causing the boiler to lockout.It is the code that the FE-24E range displays when the PCB fails internally. Check after ruling out correct power supply and connections: if the F5 persists with correct wiring and sensors, the PCB (N03G009M8) is the cause and should be replaced.
F10Fault in the control or closure of the gas valve; cannot be unlocked.Sources document that the origin may be the control circuit (the PCB) OR the gas valve itself. Verify by measuring the signal/power supply that the PCB sends to the valve: if the PCB does not correctly control the valve (signal absent or incorrect with a healthy valve), the PCB N03G009M8 is the cause. Shared cause, not exclusive to the PCB.

These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.

Technical data

Data sheet for the Fagor N03G009M8 PCB.

Catalogue reference
N03G009M8
Uniclima internal SKU
PACE24EN
Brand
Fagor
Type of part
PCBs (control boards)
Units in stock
5 units
Status
Refurbished
Warranty
1 year
Shipping
Delivery time shown at checkout
Return
14 days
Frequently asked questions

Frequently asked questions about the PCB N03G009M8

Does this auxiliary PCB for the Fagor CE-24E/1 have the reference N03G007M2?
Not for this spare part: that reference, seen in the photo of this unit, corresponds to a different part made.
Is this PCB the main control board for the Fagor FA-23E boiler?
No; it's a secondary PCB, different from the main control board.
Is this auxiliary PCB compatible with a Fagor CA-24E N?
Yes, the CA-24E N is listed among the boilers compatible with this PCB.
