Fagor Bithermal Plate Heat Exchanger FEE 20 2 B Ref. FA000070
- For 12 Fagor boilers Ecocompact / 20E and Ecocompact FEE-20
- Check for: The domestic hot water does not reach the usual temperature, especially during months of high consumption., The flow of hot water is significantly lower than before, with the boiler pressure being normal.
- Delivery to the EU in 2–6 working days · Depending on the country; cost shown at checkout
- Returns within 14 days, spare part not installed
- Inspected and tested, warranty 1 year
Is it compatible with your boiler?
Fagor boilers compatible with reference FA000070
- FE-20EEcocompact / 20E (FE-20E)
- FE20EEcocompact / 20E (FE-20E)
- ECOCOMPACT FE 20-EEcocompact / 20E (FE-20E)
- FEE-20Ecocompact FEE-20 (electronics)
- FEE-20/2 BEcocompact FEE-20 (electronics)
- FEE20/1NEcocompact FEE-20 (electronics)
- FEB-20EEcoplus FEB-20E
- FEB-20EF/1NEcoplus FEB-20E
- FA-20EFA-20E
- FA-20E NFA-20E
- CE-20ECE-20E
- CE-20E/1 NCE-20E
Can’t see your model? The printed reference takes priority. How to check it or send us a photo on WhatsApp.
How to check if Ref. FA000070 is the spare part for your boiler
-
Read the reference on your bithermal heat exchanger
It must show FA000070 on the label or the screen print. If it is not legible, do not work it out from its shape.
-
Find the model of your boiler
It is on the rating plate. Look it up in the compatible list.
-
Compare connections and body
With the original spare part, before fitting.
-
If you are unsure, send us a photo
For the screen print: we will confirm it with you before you buy.
Send photo via WhatsApp
Symptoms that require diagnosis on this spare part (bithermal heat exchanger FA000070)
The domestic hot water does not reach the usual temperature, especially during months of high consumption.
- Cause
- Limescale builds up on the heat exchanger plates, reducing their capacity to heat the water.
- What to do
- Check if the water in the area is hard and if the boiler has a water softener before deciding to replace the part.
The flow of hot water is significantly lower than before, with the boiler pressure being normal.
- Cause
- The internal channels of the heat exchanger narrow due to accumulated scale, limiting the flow of water.
- What to do
- First, check the cold water inlet filter; a dirty filter can cause the same symptom.
It is necessary to replenish pressure in the heating system more frequently than usual, without visible leaks on the outside.
- Cause
- An internal crack in the heat exchanger allows water to pass between the primary circuit and the domestic hot water circuit.
- What to do
- Check for several days if the pressure drops with the filling valve closed to confirm the leak before replacing the part.
A boiling or bubbling noise can be heard inside the boiler when heating.
- Cause
- The accumulated scale in the heat exchanger creates hot spots that cause the water to boil in those areas.
- What to do
- Check if the noise occurs only when requesting hot water; this helps to differentiate the heat exchanger from other causes.
Electrical work and opening the boiler are jobs for a technician. Repair and diagnosis
Technical sheet: bithermal heat exchanger Fagor FA000070
If you notice that the hot water comes out lukewarm or with fluctuating temperature, a technical diagnosis must confirm if you need the Fagor Bithermic Plate Heat Exchanger FEE 20 2 B Ref. FA000070. This part is responsible for transferring heat from the primary circuit to the domestic hot water instantly. When it fails, the flow of domestic hot water decreases and can cause discomfort in daily use. This heat exchanger is compatible with several models, including the Ecocompact 20E, FEE-20, and CE-20E, among others. A technician must confirm through diagnosis if it needs to be replaced when these symptoms of malfunction occur.
Frequently asked questions about the spare part bithermal heat exchanger Fagor FA000070
What fault does this plate heat exchanger of the FEE20/2B boiler resolve?
It should be checked when it loses tightness or performance. Replacement requires a technical diagnosis.
Is this heat exchanger also compatible with the Fagor FE20EFRN boiler?
Yes, the FE20EFRN is on the list of compatible boilers, along with FE20E, FEB-20E, and FEE20/2B.
How do I know if this spare part (bithermal heat exchanger) FA000070 is the right one for my Fagor boiler?
Look at the reference printed on the installed spare part (bithermal heat exchanger): it should read FA000070. Then check the model on your boiler’s rating plate. This spare part (bithermal heat exchanger) has 12 verified compatibilities, in the families Ecocompact / 20E (FE-20E), Ecocompact FEE-20 (electronica), Ecoplus FEB-20E and 2 more. If you cannot find the reference or your model is not on the list, send us a photo via WhatsApp and we will confirm it before you buy.
What does it mean that this spare part (bithermal heat exchanger) is reconditioned?
That it is not a new spare part: it is sold inspected and tested, with a 1-year warranty. If in the end you do not install it, you have 14 days to return it.
How much does shipping cost and how long does it take to arrive?
TIPSA shipping: 24/48 working hours to mainland Spain and 2–6 working days to the EU, depending on the country. No shipping to the Balearic or Canary Islands, Ceuta or Melilla.
The exact cost appears in your cart before you pay. Check delivery times and shipping rates by country.
Can I return it if it turns out not to be the right spare part for me?
Yes. You have 14 calendar days from when you receive it to return this spare part bithermal heat exchanger, provided it is uninstalled, unused and in its original packaging. The return shipping is at your expense, unless the error was ours or the spare part arrives faulty.
The exception is electronic boards and electronic components, for which returns are not accepted: they are inspected and prepared for a specific appliance and, once connected, their condition cannot be checked. Read the returns policy.
