PCB Saunier Duval Thema C 25 E Ref. S1047000

Saunier Duval boilers compatible with reference S1047000

PCB with reference S1047000. 33 verified compatibilities: F 25 E and F 24 E.

Proven compatibility

Can't see your model or have questions? The printed reference takes precedence. How to check it · Send us a photo via WhatsApp.

How to check if ref. S1047000 is the part for your boiler

The part reference, model, and equipment revision must be verified against the manufacturer's documentation.

1. Find the reference printed on the installed part and check whether it matches the catalogue reference S1047000. If it is not visible, do not identify the part from its shape alone.
2. Check the full boiler model on its data plate and look for it in the model associations on this page.
3. Compare the connections and physical body with the original part before installation.
4. If anything is unclear, send us a photo of the marking via WhatsApp before placing your order.

Symptoms that require diagnosis on the PCB S1047000

The PCB controls the ignition, modulation, and safety features of the boiler. These are the typical symptoms and what to do:

Common symptoms and faults

• 01

  The pump, the fan, or the burner stay on continuously even though the boiler should have turned off.

  Cause: One of the relays on the PCB is stuck and does not open the contact, so the component continues to receive power.

  Listen for the click of the relays when starting and stopping the boiler; if one doesn't make a sound or gets stuck, that's where the fault is before replacing the entire PCB.

• 02

  The boiler does not start the burner even though the rest of the functions are working normally.

  Cause: The relay that gives the ignition command does not close the contact and the signal does not reach the gas valve.

  Measure with the multimeter if there is continuity in the corresponding relay at the moment the boiler attempts to ignite.

• 03

  Repeated clicking sounds are heard in the boiler without anything happening.

  Cause: A faulty relay switches several times trying to close the contact without success.

  Locate which relay the noise is coming from (they are identified on the PCB) to confirm which one is faulty before deciding on the replacement.

• 04

  Different functions gradually stop responding: first the pump, then the fan.

  Cause: The relays degrade one by one with use and fail at different times.

  Note the order in which the components stop functioning; if it coincides with different relays, confirm it before replacing the entire PCB.

Fault codes Saunier Duval that require diagnosis

These symptoms can have more than one cause. If your boiler displays a fault code, send it to us via WhatsApp along with a photo of the labeling, and we'll tell you if this is the part.

Data sheet for the Saunier Duval S1047000 PCB.

Catalogue reference

S1047000

Uniclima internal SKU

PETFC25E

Brand

Saunier Duval

Type of part

PCBs (control boards)

Units in stock

0 units

Status

Refurbished

Warranty

1 year

Shipping

Delivery time shown at checkout

Return

14 days

Part data and available documentation

Contrast the label codes, PCB, and revision with the installed part; they are not necessarily equivalent references.

PCB reference

S1047000

Relays (x3)

OMRON G5Q-1, DC24V, manufactured in China, 5A 30VDC / 10A 250VAC~

Connector plastic classification

UL GF201 94V-0A / GF P/N 2036288A 2
